FRAME
aluminium 6061, InTube battery concept (IBC), thru-axle M12 (1.75) x 142mm, disc brake Post Mount
DRIVE UNIT
Bosch Performance CX, 250W, 75Nm, 25km/h
DISPLAY
Bosch Intuvia
BATTERY
Bosch PowerTube, 500 Wh
CHARGER
Bosch quick charger 4A
FORK
SR Suntour Mobie E45 LOR Lockout, air, Travel: 80mm, aluminium steerer tube 1 1/8" - 1 1/2" tapered, thru-axle
SHIFTING SYSTEM
Shimano Deore XT M8000 Shadow Plus, 11 speed
GEAR LEVER
Shimano Deore XT M8000, rapidfire
REAR SPROCKET
Shimano SLX M7000, 11-46 teeth
CHAIN
KMC e11S
CHAIN RING
Haibike Components, 16, steel
BRAKE LEVER
Magura MT4
FRONT BRAKE
Magura MT4, 180mm, 2-piston disc brake
REAR BRAKE
Magura MT4, 180mm, 2-piston disc brake
TYRES
Schwalbe Super Moto X, 62-584, 27.5" x 2.4"
RIMS
Rodi Tryp 35, with eylets, hollow rim, aluminium
FRONT WHEEL HUB
Haibike Components TheHub ++ thru-axle 15x100mm
REAR WHEEL HUB
Haibike Components TheHub ++ thru-axle 12x142mm
SPOKES
Sapim Leader, black
HANDLEBAR
Haibike Components TheBar ++ 740mm
GRIPS
XLC Comfort bo3 with wrist rest
STEM
Haibike Components TheStem ++, A-head, Bar bore: 31.8mm, 12˚
HEAD SET
A-Head Tapered, Cartridge, aluminium
SADDLE
Haibike Components TheSaddle
SEAT POST
Haibike Components The seat post ++, patent, 31.6mm, aluminium
PEDALS
VP E461 mit Reflektor, aluminium
HEAD LIGHT
Haibike Skybeamer 300 Tagfahrlicht, 100 lux
TAILLIGHT
AXA Blueline
DYNAMO
via system battery
CARRIER
system carrier, XLC Carrymore, max. 25kg
MUDGUARD
SKS, chromoplastics
KICK STAND
Ursus Mooi, adjustable
